DLMS/STS Compliant Smart Electric Meter with Class 1.0 Accuracy and 100 A Max Current for Industrial Broad Range Applications
Ask Latest Price
Video Channel
Contact Now

Add to Cart
Find Similar Videos
View Product Description
Wholesale Price DLMS/STS Compliant Electricity Meter for Industrial Broad Range Applications
DLMS/STS Compliant Smart Electric Meter with Class 1.0 Accuracy and 100 A Max Current for Industrial Broad Range Applications DLMS/STS Compliant Smart Electric Meter with Class 1.0 Accuracy and 100 A Max Current for Industrial Broad Range Applications
Flexible Payment Control
The CA368 allows utility and service providers to configure flexible payment control settings including free basic unit allocation, emergency overdraft credit, low credit warnings, and customized repayment rules.
Key Benefits
  • Meters can be extended to Split type with UIU
  • Multiple communication options: PLC/RF/LoRa/GSM wireless with AMR AMI server
  • Time of Use (TOU) based consumption recording
Technical Parameters
Parameter Specification
Nominal voltage Un 3x230/240V
Limited voltage 50%~130%Un
Nominal frequency fn 50-60Hz+5%
Basic current(Ib) 10A
Maximum current(Imax) 100A
Starting current(Ist) 0.4%IB
Active energy constant 1000imp/kWh
Accuracy as Active energy to IEC62053‐21 Class1.0
Power consumption in Voltage circuit <2W <8VA
Power consumption in current circuit <1VA
Operating temperature -25℃ to +70℃
Storage temperature -40℃ to +85℃
DLMS/STS Compliant Smart Electric Meter with Class 1.0 Accuracy and 100 A Max Current for Industrial Broad Range Applications DLMS/STS Compliant Smart Electric Meter with Class 1.0 Accuracy and 100 A Max Current for Industrial Broad Range Applications DLMS/STS Compliant Smart Electric Meter with Class 1.0 Accuracy and 100 A Max Current for Industrial Broad Range Applications
Main Features
  • Critical metrological value measurement: V, A, PF, P, etc
  • Trip on no credit or preset balance level
  • Disconnect on tamper detected
  • Configurable settings for power limit, emergency credit, debt collection, surcharges
  • Uni-directional measurement for reverse energy (SRE)
  • Advanced anti-fraud features
DLMS/STS Compliant Smart Electric Meter with Class 1.0 Accuracy and 100 A Max Current for Industrial Broad Range Applications DLMS/STS Compliant Smart Electric Meter with Class 1.0 Accuracy and 100 A Max Current for Industrial Broad Range Applications
Frequently Asked Questions
Q: Are you a trade company or a manufacturer?
A: We are an original meter manufacturer and solution provider, offering comprehensive support for your needs.
Q: Do you provide samples for testing, free or extra?
A: Samples are available for a reasonable cost.
Q: What payment terms do you accept?
A: We accept Paypal, West Union, T/T, and L/C. For payments ≤USD2000, 100% in advance. For payments >USD2000, 30% in advance by T/T with balance payment before shipment.
Q: How long is your delivery time?
A: Typically 5-10 days for stock items, or 15-30 days based on order quantity.
